Now one thing I have noticed is that the the gap between the two USB3.0 ports has been increased over the UD5H, this means that cases with large USB3.0 connectors can now get both fitted side by side,
A LED illuminates to show which one is in use. The two BIOS chips, one main and one backup, Gigabyte have this across the range of motherboards and it protects you from bad BIOS flashes or power cuts during a flash.
SATA power connector to provide extra for the expansion slots. Two SATAIII ports from the Intle chipset. Four SATAII ports from the Intel chipset. MSATA port, using this disables SATAII port#5. #Gigabyte easytune 6 open driver handle failure code#
Power button, reset and clear CMOS buttons, voltage read points.Ģ4 pin ATX, post code LED display and a USB3.0 internal header, system fan header. Those are the new 60A rated ferrite chokes, behind them (hidden under the heatsink) are the IR3550 voltage regulators.Ĩ pin ATX and one of four system fan headers, note all the fan headers are four pin also. The WiFi card is a little different than the one included with the Z77-UD5H WiFi (on the right),
#Gigabyte easytune 6 open driver handle failure manual#
Installation guide, board manual and WiFi manual. Six SATAIII cables, three with 90° ends. The outside features all the usual specifications and unique features for this board as you expect, so if you were in a shop making a purchase you can easily see whats what. With 8 of the new IR3550 rated at 60A each this board can deliver a massive 480A for the CPU (you wont use that), without needing any active cooling on the VRM's, new high capacity ferrite chokes are also used, rated also at 60A each, the IR3550 is a single chip package that replaces four individual components used previously. A cheaper budget board may claim 8 phases, but will in fact use a 6+1 (or other) PWM, 4 of these are then doubled to claim 8 phases. In the case of the Z77X-UP5 TH there are a total of 8 phases for the the CPU core alone, unlike other manufacturers this is a true 8 phases design and not a "doubling" of the PWM. Click to expand.Ultra Durable 5 has all the previous features of Ultra Durable 4,3,2 etc, but also adds a new industry leading IR3550 powerstage rated at an astonishing 60A each while remaining very efficient and cool.
